Features：
Support FEC function, can optimize the output, DDM signal monitoring, link detection (no rx not tx)
Support CDR function, can optimize the output, DDM signal monitoring, no signal shut off the function.
Support 4-service 125Mbit / s ~ 11.3Gbit / s Any rate of bidirectional service access (single card maxsupport 64)
Support 8-service 125Mbit / s ~ 11.3Gbit / s any rate of unidirectional service access (single card max supports 128)
Technical Parameters：
| system parameter |
Module type ：10Gbps (SFP+) |
| Transmission distance [km] |
2 |
10 |
40 |
80 |
| Center wavelength [nm] |
850/1310 |
1290~1330 |
CWDM/DWDM |
CWDM/DWDM |
| Max spectral bandwidth [nm] |
1 |
1 |
1 |
1 |
| SMSR [dB] |
- |
30 |
30 |
30 |
| output power [dBm] |
-7 ~ -1 |
-6 ~ -1 |
-1 ~ 2 |
0 ~ 4 |
| Extinction ratio [dB] |
> 3 |
> 6 |
> 8.2 |
> 9 |
| Rx laser type |
PIN |
PIN |
PIN |
APD |
| Mini load [dBm] |
-3 |
0 |
-9 |
-9 |
| Receive sensitivity [dBm] |
-10 |
-14 |
-16 |
-24 |
| Max dispersion allowance[ps/nm] |
n.a. |
35 |
800 |
1600 |
| Optical Path Penalty [dB] |
1 |
1 |
1 |
2 |
| Maximum return loss [dB] |
-27 |
-27 |
-27 |
-27 |
